FAN  COOLING

• Switching Power supply (SMPS) convert AC to DC, output current depends on the requirements of the power consuming equipment, Power multiple devices with different Currents/ Watts.

• PROPRIETARY Circuit solutions: High EFC, Low-loss, Long Service Life: More than 6,000 hours of service life; Aluminum shell, Low standby power consumption, High efficiency

• Imported high quality Chips: Overload / Overvoltage / Overcurrent / Short circuit protection
• High Capacity Aluminum Electrolytic Capacitors: Large Capacity, Moderate Dielectric Strength, High ESR, Polarity
• High quality EMI filter inductor made of copper: Low loss, high efficiency, good heat dissipation, stability
• Transparent cover: Dustproof ; Prevent accidental touch

INCLUDED

• 1 × switch mode power supply (SMPS),

• 1 × user's manual
• Instructions in other languages: Download in "Product Documentation".
• Not have Power Cord / Screws

PARAMETER

• Rated Power: 360 watt
• AC Input voltage: 110V (85-145V)/220V (185-265V) Alternating Current
• Frequency range: 50/60Hz
• Efficiency: ＞ 80%
• Leakage current: <0.5 mA / 230 VAC
• Product Size (mm): 21.5×11.5×5cm/8.5×4.5×2 inch
• Product Weight: 0.85kg

• Output Voltage:

• S-360-12: 12V Direct Current,
• S-360-24: 24V Direct Current,
• S-360-36: 36V Direct Current,
• S-360-48: 48V Direct Current,
• S-360-60: 60V Direct Current,
• Adjustable output voltage range: Nominal voltage ± 5%

• Difference range: ± 1%
• Working Temperature: -10 ~ +60 ℃ (Refer to the output load derating curve)

• Working Humidity: 20% ~ 90% RH
• Storage Temperature: -20 ~ +85 ℃
• Storage Humidity: 10% ~ 95% RH
• Temperature Coefficient: ± 0.03% / ℃ (0 ～ 50 ℃)
• Start, Rise, Hold Time: 200ms, 50ms, 20ms
• Vibration Resistance: 10～500Hz, 2G 10min, / 1 cycle, duration 60 minutes, each axis
• Pressure Resistance: ( between inlet and outlet) 1.5 KvAC input and housing; 1.5 KvAC output and housing; 0.5 KvAC

The maximum usage power don't exceed 80% of the full load, otherwise the service life will be greatly shortened

CHOOSE and ATTENTION

• Please use within the specified voltage range. Do not use at full load. Use under the guidance of an electrician.


• How to choose:

  If running 24*7 hours, the load does not exceed 40%.

  For device, SMPS power ≥ device power × 1.25 times. For Motor device, the peak power of the SMPS needs to be more than 2 times the power of the Motor.

• Not suitable for Speed-Regulating Motors

• Not suitable for charging Batteries

• Please switch to a suitable voltage before use
• Not waterproof
• Cooling Fan has wind noise.
• Keep a distance of more than 3m/10feet from the power amplifier to avoid filter interference.
• Not applicable to: Programming/ Speed control motor/ Dimming light/ Grow light/ Power controller /for charging Batteries.

For other voltages please contact us

• Power: 12W ~ 2400W

• Other current: 0-200A Max.
• Other voltage: DC 5V, 9V, 12V, 13.8V, 15V, 18V, 24V, 27V, 28V, 30V, 32V, 36V, 42V, 48V, 55V, 60V, 65V, 70V, 72V, 80V, 90V, 100V, 110V.
