1. ▶New upgrade: cooling fan + AL + cooling silicone film + hollow design, the perfect balance of weight and sturdiness. 2.0mm thickened aluminum shell, wear-resistant, pressure-resistant and impact-resistant, not easily deformed. Baking paint process, excellent corrosion-resistant materials, not easy to leave fingerprint traces. Low standby power consumption, high efficiency.
2. ▶Constant voltage Power supply: Output DC 12V (adj 11-13V) 150-200% Overload protection threshold. 12V DC Power supply for TV, Audio, Amplifier, Motor Driver, Servo, 3D Printer, Machine Tool, Punching Machine, Semiconductor, Parking Heater, Pump, Oil Pump, Car Audio, RGB Led 5050, Led Cob Lighting, CNC DC-DC Module, etc 〖The rated power of the transformer is the power when it is working normally (not no-load). This is different from mechanical equipment. 〗
3. ▶PCB Double-Sided Board, High precision components, complex board making process, fine lamination, mechanized and automated production. Heat and fire resistant, flame retardant, not easy to be corroded, not easy to grow mold, moisture-proof. Each MEISHILE power supply is strictly tested for nearly 2 hours within 6 hours before leaving the factory.
4. ▶Environmentally friendly and excellent packaging:Tight thickened pearl cotton perfectly protects MEISHILE power supply. More doses of fixing glue, so that the internal parts are firmly fixed to avoid the damage of transportation
5. ▶Long-term support service: Any time you have a question, please contact us immediately. Our customer service team has many years of experience in the power supply field and will assist you with pre and post-sales questions. Multi-language user manuals have been uploaded to the product guide and documentation

FAN  COOLING

• Switching Power supply (SMPS) convert AC to DC, output current depends on the requirements of the power consuming equipment, Power multiple devices with different Currents/ Watts.

• PROPRIETARY Circuit solutions: High EFC, Low-loss, Long Service Life: More than 6,000 hours of service life; Aluminum shell, Low standby power consumption, High efficiency

• Imported high quality Chips: Overload / Overvoltage / Overcurrent / Short circuit protection
• High Capacity Aluminum Electrolytic Capacitors: Large Capacity, Moderate Dielectric Strength, High ESR, Polarity
• High quality EMI filter inductor made of copper: Low loss, high efficiency, good heat dissipation, stability
• Transparent cover: Dustproof ; Prevent accidental touch

INCLUDED

• 1 × switch mode power supply (SMPS),

• 1 × user's manual
• Instructions in other languages: Download in "Product Documentation".
• Not have Power Cord / Screws

PARAMETER

• Rated Power: 1500 watt
• AC Input voltage: 110V (85-145V)/220V (185-265V) Alternating Current
• Frequency range: 50/60Hz
• Efficiency: ＞ 80%
• Leakage current: <0.5 mA / 230 VAC
• Size: 245x125x65mm / 9.65*4.92*2.55 inch
• N.W.:  1.23 kg / 2.7 ib
•

• Output Voltage:

• SE-1500-12: 12V Direct Current,

• SE-1500-24: 24V Direct Current,
• SE-1500-36: 36V Direct Current,
• SE-1500-48: 48V Direct Current,
• SE-1500-60: 60V Direct Current,
• Adjustable output voltage range: Nominal voltage ± 5%

• Difference range: ± 1%
• Working Temperature: -10 ~ +60 ℃ (Refer to the output load derating curve)

• Working Humidity: 20% ~ 90% RH
• Storage Temperature: -20 ~ +85 ℃
• Storage Humidity: 10% ~ 95% RH
• Temperature Coefficient: ± 0.03% / ℃ (0 ～ 50 ℃)
• Start, Rise, Hold Time: 200ms, 50ms, 20ms
• Vibration Resistance: 10～500Hz, 2G 10min, / 1 cycle, duration 60 minutes, each axis
• Pressure Resistance: ( between inlet and outlet) 1.5 KvAC input and housing; 1.5 KvAC output and housing; 0.5 KvAC

The maximum usage power don't exceed 80% of the full load, otherwise the service life will be greatly shortened

CHOOSE and ATTENTION

• Please use within the specified voltage range. Do not use at full load. Use under the guidance of an electrician.


• How to choose:

  If running 24*7 hours, the load does not exceed 40%.

  For device, SMPS power ≥ device power × 1.25 times. For Motor device, the peak power of the SMPS needs to be more than 2 times the power of the Motor.

• Not suitable for Speed-Regulating Motors

• Not suitable for charging Batteries

• Please switch to a suitable voltage before use
• Not waterproof
• Cooling Fan has wind noise.
• Keep a distance of more than 3m/10feet from the power amplifier to avoid filter interference.
• Not applicable to: Programming/ Speed control motor/ Dimming light/ Grow light/ Power controller /for charging Batteries.

For other voltages please contact us

• Power: 12W ~ 2400W

• Other current: 0-200A Max.
• Other voltage: DC 5V, 9V, 12V, 13.8V, 15V, 18V, 24V, 27V, 28V, 30V, 32V, 36V, 42V, 48V, 55V, 60V, 65V, 70V, 72V, 80V, 90V, 100V, 110V.
